With the rapid development of the global semiconductor industry, optical semiconductor inspection technology, as the core link to ensure the yield and performance of chip manufacturing, is facing unprecedented opportunities and challenges. At present, the semiconductor manufacturing process has entered 5nm and below nodes, and the popularity of new technologies such as three-dimensional FinFET transistors and 3D NAND has made the microstructure more complex, placing higher requirements on the sensitivity, accuracy and efficiency of detection technology. With its advantages of non-contact, high precision and high speed, optical inspection technology has become an indispensable tool in the semiconductor manufacturing process, especially in the wafer defect detection, film thickness measurement, three-dimensional topography analysis and other fields.
In order to meet the development trend and requirements of detection and measurement technology to high speed, high sensitivity, high accuracy, high repeatability, and high cost performance, many technical improvements have been made in the industry. These improvements include enhancing the light intensity of the illumination, extending the spectral range to the DUV band, increasing the numerical aperture of the optical system, increasing the optical mode of illumination and acquisition, and expanding the application of optical algorithms and optical simulation in the field of inspection and measurement. The progress of these technologies provides support for the continuous improvement of integrated circuit manufacturing technology, and also indicates that the corresponding detection and measurement technology level will continue to improve.
Time | Topics | Speakers |
---|---|---|
Host: Min Xu, Researcher, College of Future Information Technology of Fudan | ||
9:30-9:35 | Opening | |
9:35-9:55 | Optical Defect Inspection Technologies for Semiconductor Applications | Jian Chen, CTO, ZC Optoelectronic Technologies.Ltd. |
9:55-10:15 | Metrology and Inspection Solutions for Advanced Wafer Manufacturing and Advanced Packaging | Xuena Zhang, Chairwoman / CTO, Shenzhen Angstrom Semiconductor Technology Co., Ltd. |
10:15-10:35 | The Application of Scattering in the Field of Optical Semiconductor: Quantitative Detection of Silicon Carbide, Glass, Silicon Wafers, Through-Silicon Vias, and Front-End Overlay Structures | Bofang Peng, General Manager, Pure Chip. |
10:35-10:55 | Breakthroughs in the Resolution of Optical Measurement in Chip Manufacturing | Min Xu, Researcher, College of Future Information Technology of Fudan. |
10:55-11:15 | Bridging Spectral Ranges: UV-VIS to NIR in Semiconductor Metrology | Jamie Zhou, Sales Development Manager, Carl Zeiss (Shanghai) Co., Ltd. |
11:15-11:35 | The Application of Deep Spectral Technology in Optical Semiconductor Detection Technology | Jing Cui, Vice General Manager, Ideaoptics Inc. |
11:35-11:55 | Domestic Brightfield Nano-Patterned Wafer Defect Detection Equipment: Improving the Yield of Integrated Circuit Manufacturing | Coast Yan, Vice General Manager, Suzhou TZTEK Technology Co., Ltd. |
11:55-12:15 | High-Speed, High-Resolution Sensors Facilitate Semiconductor Inspection | Hongyi Wang, Marketing Director, Hefei I-TEK Optoelectronics Technology Co., Ltd. |
12:15-12:35 | Robust and Defocus-Resilient Dark-Field Wafer Inspection System: Principles and Progress | Dr. Zhenzhen Ding, Fudan University. |
Researcher, College of Future Information Technology of Fudan.
CTO, ZC Optoelectronic Technologies.LTD.
Chairwoman / CTO, Shenzhen Angstrom Semiconductor Technology Co., Ltd.
General Manager, Pure Chip.
Sales Development Manager, Carl Zeiss (Shanghai) Co., Ltd.
Vice General Manager, Ideaoptics Inc.
Vice General Manager, Suzhou TZTEK Technology Co., Ltd.
Marketing Director, Hefei I-TEK Optoelectronics Technology Co., Ltd.
PhD Candidate, Fudan University.
Optical Semiconductor Inspection Technology Forum
Standard Price¥600 / Group Price¥480
Get 3 more Forums for 2025 Optics Industry:
Standard Price¥1350 / Group Price¥1080
★ Computational Optical Imaging Technology Innovation Forum
★ Ultra-Precision Micro/Nano Optical Manufacturing Technology Forum
★ Nanoimprint Manufacturing Technology Forum
Don't wait any longer for the highest level forum alongside with CIOE 2025. If you are interested in attending this forum, SAVE THE DATE and enjoy EARLY BIRD PRICE now!
